GYTS93 outdoor single-mode armored optical cable / GYTS93室外单模铠装光缆
$**.**~$**.**/METER
$**.**~$**.**/METER
原价 **.**元每米
现价**.**元每米
Free shipping on orders over $50!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
产品描述
GYTS93 光缆的结构是将 250µm 光纤套入高模量材料制成的松套管中，松套管内填充防水化合物。缆芯的中心是一根金属加强芯，对于某些芯数的光缆来说，金属加强芯外还需挤上一层聚乙烯（PE）。松套管（和填充绳）围绕中心加强芯绞合成紧凑和圆形的缆芯，缆芯内的缝隙充以阻水填充物。涂塑不锈钢带纵包后挤制聚乙烯护套成缆。
Product Description
The structure of GYTS93 optical cable is to insert 250 µ m optical fiber into a loose tube made of high modulus material, and fill the loose tube with waterproof compound. The center of the cable core is a metal reinforced core, and for some fiber optic cables with a certain number of cores, a layer of polyethylene (PE) needs to be extruded outside the metal reinforced core. The loose tube (and filling rope) is twisted around the central reinforcement core to form a compact and circular cable core, and the gaps inside the cable core are filled with water-resistant filling material. The cable is made by longitudinally wrapping the coated stainless steel strip and extruding a polyethylene sheath.
The structure of GYTS93 optical cable is to insert 250 µ m optical fiber into a loose tube made of high modulus material, and fill the loose tube with waterproof compound. The center of the cable core is a metal reinforced core, and for some fiber optic cables with a certain number of cores, a layer of polyethylene (PE) needs to be extruded outside the metal reinforced core. The loose tube (and filling rope) is twisted around the central reinforcement core to form a compact and circular cable core, and the gaps inside the cable core are filled with water-resistant filling material. The cable is made by longitudinally wrapping the coated stainless steel strip and extruding a polyethylene sheath.
产品特点
1.具有很好的机械性能和温度特性
2.松套管材料本身具有良好的耐水解性能和较高的强度
3.管内充以特种油膏，对光纤进行了关键性保护
4.特别设计的紧密的光缆结构，有效防止套管回缩
5.良好的抗压性和柔软性
6.PE 护套具有很好的抗紫外辐射性能
Product Features
1. Has excellent mechanical properties and temperature characteristics
2. The loose tube material itself has good hydrolysis resistance and high strength
3. The tube is filled with special grease to provide critical protection for the optical fiber
4. Specially designed tight fiber optic cable structure effectively prevents sleeve retraction
5. Good compressive strength and flexibility
6. PE sheath has excellent resistance to ultraviolet radiation
1. Has excellent mechanical properties and temperature characteristics
2. The loose tube material itself has good hydrolysis resistance and high strength
3. The tube is filled with special grease to provide critical protection for the optical fiber
4. Specially designed tight fiber optic cable structure effectively prevents sleeve retraction
5. Good compressive strength and flexibility
6. PE sheath has excellent resistance to ultraviolet radiation
产品标准
符合 YD/T 901和IEC 60794-1 等标准
运输/储存/使用温度-40℃至+70℃
Product standards
Compliant with YD/T 901 and IEC 60794-1 standards
Transportation/storage/use temperature -40 ℃ to+70 ℃
Compliant with YD/T 901 and IEC 60794-1 standards
Transportation/storage/use temperature -40 ℃ to+70 ℃
